Atosa ACEF-16 Single Tank Electric Countertop Fryer, 16 lb Capacity
Atosa ACEF-16 Single Tank 16lb Electric Countertop Fryer
Product Features:
- Configuration: 1 basket
- Fat capacity: 16 lbs
- Dimensions: 11-1/4"W x 18-1/2"D x 17-3/16"H
- All stainless steel construction
- Nickel-plated fry basket with cool-to-touch insulated handle
- Removable stainless steel fry basket with handle
- Thermostat range: 70–375°F
- High-temperature control with manual reset
- Built-in basket hook
- Easy-to-remove control box and swing-up element
- Attached power cord and plug
- 3.8kW, 240V/60/1-ph, 15.1 amps
- NEMA 6-20P
The Atosa ACEF-16 is a single-basket electric countertop fryer with 16 lbs of fat capacity — higher oil volume than the ACEF-10 for operations that need longer fry cycles between oil replenishment and the higher heat recovery of a larger oil mass. All stainless steel construction with nickel-plated basket and cool-to-touch insulated handle. 70–375°F thermostat and high-temperature manual reset. Built-in basket hook, removable control box, and swing-up element for easy cleaning.
At 3.8kW on 240V, the ACEF-16 delivers the heating power needed to recover temperature quickly between fry loads. NEMA 6-20P plug. 15.1 amps.
The Atosa ACEF-16 steps up from the 10 lb two-basket model to a single-basket, 16 lb fat capacity unit — a configuration that prioritizes oil mass and heat recovery over the two-basket split capacity of the smaller model. A larger oil mass retains heat more effectively when food is introduced, shortening the temperature recovery time between loads and maintaining more consistent frying temperatures through continuous service. For operations frying in volume on a single item type — french fries, chicken tenders, donuts — the single 16 lb tank outperforms a split 10 lb two-basket unit for throughput and temperature consistency.
At 3.8kW on 240V, the ACEF-16 delivers the electrical power needed to heat 16 lbs of oil efficiently and recover temperature quickly after a cold food load. The step up from 120V to 240V is the practical tradeoff for this higher output: a 240V circuit is required, but the reward is the heating performance that a 120V unit can't achieve at this oil volume. NEMA 6-20P plug requires the appropriate outlet.
All stainless steel construction throughout, with the same nickel-plated basket and cool-to-touch insulated handle as the smaller models. The 70–375°F thermostat covers the full commercial frying temperature range. High-temperature manual reset provides the safety backstop against thermostat failure. The swing-up element and removable control box allow complete tank cleaning between sessions without damage to electrical components.
The single-basket format simplifies the frying workflow for operations running dedicated fry programs — one basket, one product type, full focus on producing consistent output from the full oil volume. Built-in basket hook for draining between loads.
A capable electric countertop fryer for food service operations that need 240V output and 16 lbs of oil capacity in a compact countertop footprint.
WARNING - CA Prop 65 | Product Weight (lbs) | 18.4 |
|---|---|
| Product Width (in) | 11.25 |
| Product Depth (in) | 18.5 |
| Product Height (in) | 17.25 |
| Fry Pot Width (in) | 8.75 |
| Fry Pot Depth (in) | 11.13 |
| Fry Pot Height (in) | 7.88 |
| Fryer Capacity | < 35lb |
| Fryer Capacity (lb) | 16 |
| Amps (A) | 15.1 |
| Voltage | 208-240v/60hz/1ph |
| Plug Type | NEMA 6-20P |
| Exterior Material | Stainless Steel |
| Power Type | Electric |
| Standard Warranty | 1yr Parts/Labor |
| Manufacturer | Atosa |
| MPN | ACEF-16 |
| SKU | 2A555 |
